S-8561 Henry Receiver, Vertical 1-5/8" ODS

The function of a Liquid Refrigerant Receiver is to store liquid refrigerant to provide continuous flow of liquid refrigerant to the expansion device and to provide storage for the refrigerant charge during system service or maintenance.

Applications

Liquid Refrigerant Receivers are installed in air conditioning and refrigeration systems. The Receiver is installed after the Condenser in order to collect the condensed refrigerant to allow a continuous liquid supply to the expansion device. Liquid Receivers are also used to store the refrigerant charge while the system is pumped down for service or maintenance.

Main Features

• ODS refrigerant connections
• NPT relief device fitting
• (3) 1/2 NPT fittings for sight glasses or level switches on 14” diameter and larger
• Mounting legs on all models
• Custom models available upon request
