IR-F9 CO2 Honeywell Manning AirScan Infrared Sensors

• Long-Lasting Performance
• ATMOS™ Technology
• SensorCheck™ Technology
• Superior EMI/RFI shielding

Diffusion-Design Sensor

• Has no moving parts and doesn’t require pumps or filters
• All points of detection can be monitored continuously at an affordable cost

Versatility

• Can be used with any Honeywell Analytics readout
• Standard range of 0-3,000 ppm, can be rescaled for lower trip points
• Provides a linear output of 4/20 mA as a function of refrigerant concentration
• Simple, real-time calibration eliminates maintenance downtime
• Automatically adapts to fluctuating temperatures

Long-Lasting Performance

• Unique internal reference channel compensates for dust particles, source degradation, humidity and temperature fluctuation, food odors, chemical cleaners, etc.

ATMOS™ Technology

• Allows for operation down to -60°F and in condensing humidity environments or during washdown
• Automatically adapts to its environment and provides accurate and reliable performance under the harshest conditions

SensorCheck™ Technology

• Checks operating parameters of sensors and sends a notification output signal if an anomaly is identified
• Tests the sensor every 24 hours for electrical viability
• Indication can be detected by a Manning gas monitor or PLC

Housing

• High-mass metal bench provides structural and thermal stability and greater immunity to vibration
• Superior EMI/RFI shielding
