Hansen's specially designed Gauge, Purge, and Transducer Valves feature tough, forged steel bodies, compact size, and polished stainless steel stems.
List Price
$161.00
List Price
$161.00
Web Price
$107.33
Details
Hansen's specially designed Gauge, Purge, and Transducer Valves feature tough, forged steel bodies, compact size, and polished stainless steel stems. Their patented o-ring plus packing dual-seal design and polished stainless steel stems provides leak-free packing. The safety stem design prevents removal of stem from body or stem "blowout". A Long Neck  version is available that provides extra clearance for gauge-turning rotation. They are available in 1/4 " or 3/8" MPT or FPT globe or angle sizes and styles. Hansen's Gauge, Purge, and Transducer Valves are available with seal caps, bar handles, or bare stems. Often used to isolate pressure gauges on regulators, these valves can also be used to pump out, purge, and meter refrigerant liquid or gas.
More Information
| Weight | 5.050000 |
|---|---|
| Condition | New |
| Brand | Hansen |
| Bar Handle | Steel, zinc plated |
| Body | Forged steel, ASTM A105, zinc plated |
| Cap O-ring | Neoprene |
| Seal Cap | Glass filled polymer |
| Stem | Stainless steel, polished, ¼" square flats |
| Stem Packing | Graphite composite plus neoprene O-ring in series |
| Packing Nut | Steel, zinc plated |
| Safe Working Pressure | 400 psig (28 bar) SWP 600 psig (41 bar) available upon request |
| Operating Temperature | -60°F to +240°F (-50° to+115°C) |
| Width | 3.0000 |
| Height | 3.0000 |
| Depth | 5.0000 |
