148B5416 Danfoss Hand expansion valve type REG-SA 25, globe, 1 Female Pipe Thread cone A

Hand expansion valve type REG-SA 25, globe, 1" FPT, cone A

Web Price $249.70 List Price $340.50 List Price $340.50

Qty:

Add to My Parts

Details

REG-SA are angleway and straightway hand-operated regulating valves, which act as normal shut-off valves in closed position. REG-SA with the A cone is designed for expansion lines. The valves are designed to meet the strict quality requirements on refrigerating installations specified by the international classification societies and are carefully designed to present favourable flow conditions and accurate linear characteristics.

More Information

More Information
Weight	8.880000
Condition	New
Brand	Danfoss
Port Size	1"
Body Material	Steel
Minimum Temperature Range C	-60 °C
Minimum Temperature Range F	-76 °F
Maximum Temperature Range F	302 °F
Maximum Temperature Range C	150 °C
Inlet Connection Type	NPT
Refrigerants	Applicable to HCFC, HFC, R717 (Ammonia), R744 (CO2), Propane, Butane, Iso-Butane and Ethane.
Maximum Working Pressure (PSIG)	754 psig
Maximum Working Pressure (BAR)	52 bar
Outlet Connection	1"
Inlet	1"
Type	REG-SA 25
GTIN/UPC	5702428474290
