120-SS-2-RTT-L-015 Flo-Tite 1/2 Stainless Steel Economy Ball Valves, EconoChem 120

The Flo-Tite ECONO-CHEM Series is designed as a split body, three-piece construction, to allow ease of access for maintenance of the valve ball and seat without special tools. This line of valves utilizes the "free-floating" ball principle. The ball is not fixed but is free to move with the line pressure. As a result, these valves are capable of tight shut off with the flow in either direction or dead-ended, regardless of the position of the valve in the line. The downstream seat, which is opposite the pressurized side of a closed valve, must carry the load exerted by the line pressure on the ball, while the upstream seat is subject to little load or wear. For this reason, it is sometimes possible to increase useful seat life by turning the valve end to end in the pipeline.Valve Features:Three Piece Body, Full Port DesignThreaded, Socket-Weld or Butt Weld EndsBody: CF8M, 316SSRTFE Seats or TFMSize Range: 1/4" to 4"Pressure Rating: 1000 MAWP/WOGTemperature Range: (-20? F - 400? F)Design AdvantageISO 5211 Direct-Mounting Pad – Provides for precise shaft alignmentThree Piece Swing Out Design for easy maintenanceImproved Seat Material – Extends cycle life and reduces torqueBlowout-proof StemLocking Device standard for valves with handles
