082H0162, AMV 435 24V 7,5-15s/mm 20mm 400N
SKU
082H0162
Brand:

082H0162, AMV 435 24V 7,5-15s/mm 20mm 400N

24V AC 3 Point Floating Control | 400N Closing Force | 20mm Stroke | For AB-QM 1-1/2 to 4 in Valves
Web Price $298.02 List Price $566.71 List Price $566.71
Details

A failed actuator leaves a control valve stuck wherever it stopped, and the zone it serves drifts out of setpoint until the drive is replaced. The Danfoss AMV 435 (082H0162) is a 24V AC gear actuator that restores floating point control on Danfoss AB-QM pressure independent control valves and VRG, VRB, VL, and VF control valves.

Professional Installation Required

Installation, wiring, and maintenance should be performed by qualified, authorized personnel only. Switch off the power supply before wiring the actuator, and depressurize the system before mounting.

Built for Floating Point Control

The AMV 435 accepts a 3-point floating signal, so it works with controllers and building automation systems that issue simple open and close commands. Selectable stem speed lets you match the actuator to the response of the control loop.

Matched to Danfoss Control Valves

One actuator covers medium-size AB-QM pressure independent control valves along with the VRG, VRB, VL, and VF valve series, simplifying spare parts for facilities that run mixed Danfoss valve families.

Hands-On Commissioning

Manual operation lets technicians set valve position by hand during commissioning, balancing, or troubleshooting.

Choosing the Right Actuator

The AMV 435 is a non-spring return actuator with no position feedback output. For applications that require a fail-safe position or a position signal back to the building automation system, select a spring return or feedback-equipped actuator.

Technical Specifications

Brand: Danfoss

Model: AMV 435

Code Number: 082H0162

Actuator Type: Electric gear actuator

Supply Voltage: 24V AC

Control Signal: 3-point floating

Position Feedback: None

Power Consumption: 2 W

Closing Force: 90 lbf (400 N)

Stroke: 0.79 in (20 mm)

Speed: 8 s/mm or 15 s/mm, selectable

Safety Function: Non-spring return

Manual Operation: Yes

Ingress Protection: IP54

Electrical Protection Class: II

Ambient Temperature: 32°F to 131°F (0°C to 55°C)

Storage Temperature: -40°F to 158°F (-40°C to 70°C)

Cable Included: No

Compatible Valves: AB-QM 1-1/2 in to 4 in (DN 40 to 100); VRG and VRB 1/2 in to 2 in (DN 15 to 50); VL and VF 1/2 in to 3 in (DN 15 to 80)

Net Weight: 1.28 lb (0.582 kg)

More Information
More Information
Weight 5.050000
Condition New
Brand Danfoss
