027H9099 Danfoss ICAD 600AE Regulating Valve Actuator w/o Cables

ICAD 600AE Regulating Valve Actuator w/o Cables

List Price $3,359.99 List Price $3,359.99 Web Price $2,274.46

Qty:

Details

ICAD 600AE Regulating Valve Actuator w/o Cables

More Information

More Information
Weight	3.660000
Condition	New
Brand	Danfoss
EAN	5715162143926
Maximum Ambient Temperature (C)	50°C
Minimum Ambient Temperature (C)	-30°C
Maximum Ambient Temperature (F)	122°F
Minimum Ambient Temperature (F)	-22°F
Max Analog Input Current Opt (mA)	20 mA
Min Analog Input Current Opt (mA)	0 mA
Max Analog Input Volt Opt (V) DC	10 V
Min Analog Input Volt Opt (V) DC	0 V
Cable (in/m)	1.5 meters (59")
Control cable size [AWG]	7 x ∼24 AWG
Control cable size [mm2]	7 x 0.25 mm, Ø6 mm
Digital Output-Ext supply [V] DC [Max]	24 V
Digital Output-Ext Supply [V] DC [Min]	5 V
Digital Output-Load (Ohm)	50 Ohm
Digital Outputs (do) PC	3 pc
Digital Output-Max Load (mA)	50 mA
Display Type	LCD
Enclosure Rating	IP67
Enclosure rating Nema (~)	6
Parts Program Name	ICM
Load Analog Input Current [Ohm]	200 Ohm
Load Analog Input Voltage [Ohm]	10000 Ohm
Load Analog Output Max [Ohm]	250 Ohm
Product Description	Actuator
Supply Cable Size [AWG]	3 x ˜22 AWG, ø0.19"
Supply Cable Size [mm2]	3 x 0.34 mm, ø4.8 mm
Supply Voltage [V] DC	24 V
Supply Voltage Load [A]	1.2 A
Supply Voltage Tolerance [%] [Max]	10%
Supply Voltage Tolerance [%] [Min]	-15%
Temperature range [°C] [Max]	50°C
Temperature range [°C] [Min]	-30°C
Temperature range [°F] [Max]	122°F
Temperature Range [°F] [Min]	-22°F
Type	ICAD 600AE
Product Series	ICAD 600AE
UL Approval File Name	REFRIGERANT VALVE 53R0
Used for Product	ICM 20 ICM 25 ICM 32
