SKU
018F6193
Brand:

018F6193 Danfoss Coil 10W 220/230V AC 50/60HZ DIN CONN.

Product name: Solenoid coil, Type: BE230CS, Supply voltage [V] AC: 220 - 230, Coil connection: DIN Spade + Cap, Frequency [Hz]: 50/60 Hz, Power consumption [W] 60Hz: 14.0, Power consumption [W] 50Hz: 17.0
List Price $84.72 List Price $84.72 Web Price $58.07
Estimate shipping for this product
Details
Danfoss solenoid valves and coils are usually ordered separately to allow maximum flexibility, enabling you to select a valve and coil combination to best suit your needs.The Danfoss coil program consists of both the easy-to-handle Clip-On system and traditional coils with threaded fastener.Danfoss offers a wide range of application specific coils for e.g. steam or hazardous areas. The coils are available with approvals such as EN60730-1, EEx/ATEX, and UL.Features:Encapsulated coils with long operating life, even under extreme conditionsStandard coils for AC or DCStandard coils from 12 V – 400 V, 50, 60, 50 / 60 Hz or DCStandard coils available with:Cable plugsIndustrial plugsTerminal box3 core cableJunction boxConduit hub
More Information
More Information
Weight 5.050000
Condition New
Brand Danfoss
Coil Type BE
Supply Voltage [V] DC 220 V - 230 V
Solenoid Valve Type EVR 2 – EVR 40 (NC)
EVR 6 – EVR 22 (NO)
EVRH 10 – EVRH 40
EVRC
EVRA
EVRAT
EVRS/EVRST
EVM (NC)
